FS-8000
Suitable for various truck and bus tyres. Due to the properties of nitrogen, it ensures the stability of vehicle tyrepressure and the safety of vehicle driving. With rapid pressurization system and rapid nitrogen generating system. Water cooling system with thermostatic control, which ensure safe use oftyre inflation charging hose. With standard configuration external 300-liter gas storage tank.
Product Description
| Item | Details |
|---|---|
| Power supply | 380V/50 - 60Hz |
| Power | 2.0Kw |
| N₂ Purity | 95 - 99.5% |
| Operation Temp | +5℃ - +40℃ |
| Compressed Air Pressure Required | 0.8 - 1.2Mpa |
| Air compressor discharge rate | ＞1.08M³/min |
| NO supercharger, Output N₂ Pressure | ＜116Psi/8Bar/0.8Mpa |
| Supercharged N₂ Output | ＜232Psi/16Bar/1.6Mpa |
| N₂ Output | 160L/min |
| Truck tyre (10.00/20 R75 size) | 15Tyres/Hour |
| N.W. | 238 Kg |
| G.W. | 263 Kg |
| Storage tank weight | 97 Kg (300L) |
| Dimension | 1700(H)×930(L)×640(W)mm |
