HY1100DFE Diesel Engine

1.Rated Output:10.2kw@3000rpm
3.Fuel Tank Capacity:6.5L
4.Electric Starter
5.Power Take Off: Crankshaft
6.Application:Generator, Agriculture Machinery, Construction Machinery, Boat etc
Product Description

HY1100DFE Air Cooled Single Cylinder Diesel Engine

1105.jpgHongyang HY1100DFE Diesel engine is one air-cooled single-cylinder direct injection diesel engine is a reliable and efficient power source known for its exceptional performance and durability.

1.Rated Output:10.2KW/14HP@3000rpm


3. Roation Speed:3000rpm

4. Fuel Tank Capacity:6.5L

5. Power-Take-Off: Crankshaft

Model No:HY1100DFE
Type:Air Cooled Single Cylinder Four Stroke Direct Injection Diesel Engine
Compression Ratio:18:01
Rated Output: KW/HP10.2KW/14.0HP
Roation Speed 3000rpm
Fuel Type:0# or -10# Light Diesel
Fuel Tank Capacity:6.5L
Lube TypeAbove CD Grade or SAE 10W-30, 15W-40
Lube Capacity:1.8L
Starting System:Electric Starter
Net Weight:
Packing Dimension(LxWxH)525x490x595mm
